SUNMI P2 SMARTPAD

Description

Integrated PIN Pad for Seamless Checkout

The SUNMI P2 SMARTPAD is a compact, ergonomic smart payment terminal built to accelerate and simplify checkout experiences across retail, kiosks, and hospitality settings. Designed for versatility, it supports a wide range of payment types and is ideal for both countertop and self-service environments.

---

Key Features

• 4” Horizontal Color Display
  Wide landscape screen for better visibility and user interaction.

• Ergonomic Keypad Design
  15 raised, backlit keys optimized for accurate and fast PIN entry.

• Multiple Payment Methods
  Chip & PIN, Chip & Sign, Contactless (NFC), QR Code, Magstripe, Apple Pay, Google Pay.

• Power Over Ethernet (PoE) Support
  Simplifies cable management and device deployment.

• Optional Front Camera (0.3MP or 5MP)
  Enables barcode scanning and photo capture.

• High Security
  PCI PTS 6.x Certified, EMV-compliant, built to protect every transaction.

---

Ideal Use Cases

• Multilane Checkout & Retail Counters
  Improve efficiency and customer flow with fast, intuitive payments.

• Self-Checkout Kiosks
  Reduced wait times and smoother user experience.

• Restaurants & Stores
  Easily supports all preferred payment options, PIN and signature included.

---

️ Specifications

• OS: SUNMI OS (based on Android 9.0)

• Processor: Quad-Core Cortex-A53, 1.3GHz

• Memory Options:

  • 1GB RAM + 8GB ROM

  • 2GB RAM + 16GB ROM

• Display: 4” WVGA (480×800), capacitive touch

• NFC: Supports Type A/B, MIFARE, PayPass, PayWave

• Magstripe & IC Card Reader: ISO-compliant, bi-directional

• Connectivity: Wi-Fi (2.4GHz/5GHz), Bluetooth 4.1, LAN, RS232, USB-C

• Protection: IP53-rated – resists spills and splashes

• Dimensions: 181.85 x 117.8 x 54.5 mm

• Weight: Approx. 385g

---

Optional Accessories

• Rotatable Mount (easy customer access)

• Stylus Pen (for e-signatures)

• Customizable Multi-function Cable

---

Note: Designed for businesses that want secure, modern payment capabilities in a durable, compact, and customer-friendly terminal.
